| Motherboard | ||
| BIOS | 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
|
| Form Factor | Micro ATX Form Factor; 24.4cm x 24.4cm | |
| PCI | 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU: - 3rd Generation AMD Ryzen processors support PCIe 4.0 x16 mode - New Generation AMD Ryzen with Radeon Graphics processors support PCIe 3.0 x16 mode 1 x PCI Express x16 slot (PCIEX2), integrated in the Chipset: - Supporting PCIe 3.0 x2 mode 1 x PCI Express x16 slot (PCIEX1_2), integrated in the Chipset: - Supporting PCIe 3.0 x1 mode 1 x PCI Express x1 slot (PCIEX1_1), integrated in the Chipset: - Supporting PCIe 3.0 x1 mode |
|
| Memory Type | Dual-Channel Architecture | |
| Memory Slots | 4 x DDR4 memory slots | |
| Supported Memory | 3rd Gen AMD Ryzen Processors: Support for DDR4 4000(O.C.) / 3600(O.C.) / 3333(O.C.)/ 3200/ 2933/ 2667/ 2400/ 2133 MHz memory modules New Generation AMD Ryzen with Radeon Graphics processors: Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200 /2933 /2667 /2400 /2133 MHz memory modules |
|
| Maximum Memory | support up to 128GB | |
| Graphics | Integrated into the 3rd Generation AMD Ryzen with Radeon Graphics processors: 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz |
|
| HDMI | 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz | |
| USB (s) | 4 x USB 3.2 Gen 1 ports on the back panel Chipset: 2 x USB 3.2 Gen 1 ports available through the internal USB header 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header) |
|
| LAN Port (s) | Realtek GbE LAN chip (1000 Mbit/100 Mbit) | |
| Supported Storage | 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs: 3rd Generation AMD Ryzen™ processors support SATA and PCIe 4.0 x4/x2 SSDs 3rd Generation AMD Ryzen™ with Radeon™ Graphics processors support SATA and PCIe 3.0 x4/x2 SSDs 1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2260/2280 SSDs: Supporting SATA and PCIe 3.0 x2 SSDs 4 x SATA 6Gb/s connectors, integrated in the Chipset: Support for RAID 0, RAID 1, and RAID 10 |
|
| Audio | Realtek ALC887 codec High Definition Audio 2/4/5.1/7.1-channel |
|
| Internal I/O Ports | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 2 x addressable LED strip headers 2 x RGB LED strip headers 1 x CPU cooler LED strip/RGB LED strip header 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 1 x USB 2.0/1.1 header 1 x serial port header 1 x Clear CMOS jumper 1 x Q-Flash Plus button |
|
| TPM (Trusted Platform Module ) | 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) | |
| Manufacturing Warranty | 03 years warranty | |
The B550M Aorus Elite is fully compatible with AMD Ryzen 5000/4000G Series and AMD Ryzen 3rd Generation Processors, ensuring that you can harness the full power of these cutting-edge CPUs for seamless multitasking and high-performance computing.
Enjoy lightning-fast network connectivity with the integrated 2.5 Gigabit Ethernet LAN port. This feature allows for rapid data transfer, smooth online gaming, and lag-free streaming experiences.
Gigabyte's Q-Flash Plus feature simplifies the process of updating the motherboard's BIOS. With a USB flash drive, you can update the BIOS without the need for a CPU, GPU, or memory, ensuring a smooth and straightforward update process.
The motherboard boasts an Ultra Durable PCIe 4.0 x16 slot, providing lightning-fast data transfer speeds for your graphics card. This enables you to unlock the full potential of PCIe 4.0 compatible GPUs, delivering enhanced gaming and graphics performance.
Gigabyte's Aorus Elite series is known for its premium build quality and reliable components, ensuring stability and longevity for your PC build.
The motherboard is equipped with multiple fan headers and advanced cooling options, enabling you to maintain optimal temperatures during heavy workloads or gaming sessions.
The latest price of Gigabyte B550M Aorus Elite Micro ATX Motherboard in Bangladesh is 17,000৳. You can buy the Gigabyte B550M Aorus Elite Micro ATX Motherboard at the best price from our website or visit our showrooms.
The Gigabyte B550M Aorus Elite AMD Micro ATX Motherboard is a feature-packed solution for users looking to build a powerful and reliable PC with AMD Ryzen processors. With support for the latest Ryzen CPUs, blazing-fast 2.5GbE LAN, easy BIOS updates with Q-Flash Plus, and the performance benefits of Ultra Durable PCIe 4.0 x16 Slot, this motherboard ensures you get the most out of your system. Whether you're a professional seeking top-tier performance or an avid gamer aiming for smooth gameplay, the B550M Aorus Elite delivers on all fronts. Upgrade your PC with this motherboard and experience a seamless computing experience like never before.
